Gravely Compact Pro 34" Compact Zero Turn Mower | 15.5hp | 34" Deck

Description

Description

Gravely Compact Pro 34” Zero-Turn Mower: Full Commercial Power in a Compact Size

Ideal for landscapers and pros who need compact power without sacrificing performance.

Key Features of the Gravely Compact Pro 34″

• Powered by a 15.5 hp Kawasaki FX481V Engine that touts a heavy-duty canister air cleaner to optimize performance in all conditions and extend engine life.
• Fuel Tank design Increases stability and improves machine handling and visibility.
• Smaller Footprint the Compact-Pro® easily passes through gates as narrow as 36 inches and nimbly manoeuvres around common residential obstacles.
• Hydro Gear ZT-3100 Dual hydrostatic transmission.
• Seat Isolation Removes vibrations to decrease fatigue by absorbing the rough terrain so your body doesn’t have to.
• Cut selection Offers 17 cutting positions, ranging from 25.4 mm – 127mm, to make your lawn look its best.
• Fabricated deck 10 GA. Steel with 10 GA. spindle reinforcement.
• Forged Aluminium cutter spindles with sealed ball bearings.
• Fully welded tubular frame offers a superior and more robust welded tubular frame.
• Productivity – 2.4 acres per hour.

Specifications

Warranty Information

• Domestic Warranty: 4 Years / 750 Hour Domestic Warranty
• Commercial Warranty: 4 Years / 750 Hour Commercial Warranty

Miscellaneous

• Blade(s): 2 x Bar Blades

Dimension Specs

• Dry Weight: 334.3kg
• Height: 1155 mm
• Width: 911.8 mm With Chute Up
• Length: 1905 mm

Zero Turn Mower Specs

• Ground Speed – Forward: Up To 11.2 km/h Forward
• Brakes: Hand Brake
• Seat: High Back with EVC Suspension
• Construction: Frame 1″ x 3″ STEEL Tubular Frame Welded
• ROPS: ROPS Not Supplied with Unit
• Controls: Hand-operated choke, throttle, ignition switch, electric mower clutch, Hand Park brakes
• Cup Holder: Yes
• Deck Lift: Foot Operated
• Deck Construction: Fabricated 10 Gauge with 10 Gauge Spindle Reinforcement
• Blade Tip Speed: 17,250 FPM
• Blade Drive: V-Belt Drive to Spindles with Electric Clutch. Spring Tension Idler Pulleys for Extended Belt Life
• Spindles: Forged Aluminium with Sealed Ball Bearings
• Drive System: V-Belt Drive from Engine Crankshaft
• Discharge Chute: High Density, Rubberised
• Steering: Twin-Lever Steering Provides Independent Control of Each Drive Wheel. Speed, Forward, Reverse, and Turns are All Controlled With Hand-Operated Controls.

Engine and Fuel Specs

• Engine: Kawasaki FX481V
• Engine (cc): 603 cc
• HP: 15.5 hp
• Cooling: Air Cooled Flywheel Fan
• Fuel: Unleaded Fuel – Maximum of 10% Ethanol in Fuel (see engine manufacturers specifications)
• Fuel Filter: Replaceable, Automotive-Type
• Oil Filter: Spin-On Engine Oil Filter / Total Oil Capacity 1.7 Litres with Filter
• Air Filter: Multi-Stage Remote Canister Heavy Duty Air Filter System
• Fuel Capacity: 27.1L
• Governor: Mechanical

Safety Features:

• Safety Features: Operator Presence System Connected to Clutch, Seat, and Park Brakes.

Hydrostatic Drive System Specs:

• Hydrostatic Drive System: Dual hydrostatic
• Drive Cooling: Transmission mounted fans
• Pumps: Hydro Gear ZT-3100

Cutting Dimensions

• Cutting Widths: 34″ (863 mm) Cut Side Discharge
• Cutting Height(s): 25 mm – 127 mm
