Cosmo Bully NBM Series

Description

Description

The Cosmo Bully NBM Series Mulcher is a multi-purpose implement. Its robust design makes light work of bracken, as well as prunings and undergrowth (up to 30mm).

A 2,295 rpm rotor speed, coupled with a rear opening flap, gives the operator flexibility of a quality finish on grassy applications like paddocks and parks and gardens, regardless of grass height. The NBM Series Mulcher has two bolted mounting positions (21cm apart) allowing the operator to offset the implement on the tractor’s three-point linkage.

Models

TNBM145 – 57″/1.45m
TNBM155 – 61″/1.55m
TNBM175 – 69″/1.75m

Specifications

Description – Bully TNBM145 / TNBM155 / TNBM175 Flail Mulchers
Side transmission – Belt drive
Belts – TNBM145 / TNBM155 – Three (3) TNBM175 – Four (4) SPAB typeGearbox – 50hp, 540rpm with free wheel clutch
PTO shaft/clutch – Series 4
Skids – Adjustable, Four (4) positions
Rear Roller – Ø121mm, height adjustable, six (6) positions
Finish – Powder coated
Rotor swing dia. (mm) – 350
Rotor diameter (mm) – 108
Rotor speed (rpm) – 2295
Type of blade – Hammer | No. of blades – 24 (TNBM145) / 24 (TNBM155) / 28 (TNBM175)Tower position/offset – Fixed/bolt on with two (2) mounting positions, 210mm apart
Guarding – CE compliant
Overall width (mm) – 1685 (TNBM145) / 1785 (TNBM155) / 1985 (TNBM175)
Working width (mm) – 1450 (TNBM145) / 1550 (TNBM155) / 1750 (TNBM175)
Cutting height (mm) – 54
Tractor range (hp) – 30-50 (TNBM145) / 35-50 (TNBM155) / 40-50 (TNBM175)
Weight (kg) – 355 (TNBM145) / 362 (TNBM155) / 376 (TNBM175)
